TITAN is located in Jinan, ShanDong province. It was established in 2004 and is an enterprise specializing in the export of heavy duty lowbed. Among them, the 100t lowbed for sale is one of our best-selling model. TITAN vehicle has advanced equipment, large scale and strong professional strength, and exports to countries all over the world, especially in Africa, Southeast Asia and South America.
The lowbed for sale series products are suitable for the transportation of various steel materials such as heavy machinery and equipment, large objects, highway construction equipment, large tanks, power station equipment, etc. The whole lowbed transport is optimally designed, flexible and diverse, and the frame bearing surface can be designed according to the user's requirements to meet your transportation needs for various special goods.
Titan can provide you with a variety of specifications of heavy duty lowbed transport vehicles to meet your different cargo needs, including 2, 3, and 4 axles, 2 line 4 axle lowbed trailer, 3 line 6 axle lowbed trailer, 4 line 8 axle lowbed trailer, ect. The load ability does not wait from 40-150 tons. And 2 line 4 axle lowbed trailer is one of the most popular model in TITAN.
2 Line 4 Axle 100t Heavy Duty Lowbed Trailer Transport for Sale in Zimbabwe
2 Line 4 Axle 100t Heavy Duty Lowbed Trailer Transport for Sale in Zimbabwe
2 Line 4 Axle 100t Heavy Duty Lowbed Trailer Transport for Sale in Zimbabwe
Model: 2 line 4 axle lowbed trailer
Loading capacity: 80-100 tons
Overall dimension: 15545mm * 2690mm *1500mm
Axles: 4 line 8 axle
Suspension: Heavy duty mechanical spring suspension
Leaf spring: 10 pcs
Rim: 8.0-20
Tire: 16 units, 11.00R20
King pin: 90#
Bottom Platform: 5mm thick checkered plate
Ladder: Hydraulic ladder
Landing gear: JOST/TITAN brand
Brake system: WABCO brand
Gooseneck: Optional
ABS: Optional
Electical system: LED lights
Voltage: 24V
Light: LED light
Tool box: 1 pcs
Socket: 7-pin socket
Shipping method: Transport By bulk cargo shipping or RORO shipping
1. TITAN heavy duty lowbed main baem adopts a height of 550mm and a thickness of 14mm. And the main beam of TITAN lowbed trailer is made of HG60 high strength structural steel. HG60 high strength steel bearing capacity is 5 times that of the trailer made of Q345 steel. And it has a yield strength of ≥620Mpa, which is more durable and stronger than ordinary steel. Its bearing capacity is 5 times that of the trailer made of Q345 steel.
2. TITAN lowbed transport can optionally equip hydraulic ladder, spring ladder or foldable hydraulic ladder. The plates of the cargo frame are low, which guarantees the stability of transportation. It is suitable for carrying various types of engineering machinery, large equipment and steel.
3. The side beam of lowbed for sale adopts "H" shape design and also is welded with HG60 steel. With a height of 300mm, width of 140mm and thickness of 8mm. Its bearing capacity is twice that of other steel, and it will not deform after ten years of use. Anti - turbulence ability increased about 3 times.
4. TITAN heavy duty lowbed use 16 ton brake system axle, our axle has 15 years of experience in production with a better bearing capacity and good braking effect. Other factories use 13 ton brake system axle. TITAN lowbed transport braking system, effective braking, fast braking response, braking distance reduction of more than 5 meters.
Through this video below, you can learn about different types of lowbed semi-trailers, as well as the process, testing, packaging and customer feedback, etc.
Welcome to contact us !
